Current Transformer (Split Core)
Low-voltage current transformers for metering and protection with multiple accuracy classes and core types
verifiedIEC 61869-2verifiedIEC 60044-1verifiedCEverifiedRoHS
Key Features
- check_circleMultiple primary current ratings
- check_circleMultiple accuracy classes
- check_circleMultiple enclosure types
- check_circleFlexible mounting options
- check_circleHigh accuracy metering
- check_circleRetrofit split-core options
Specifications
| types | Ring Type (solid-core),Split Core (retrofit) |
| burden | 2.5 VA to 30 VA |
| humidity | Up to 95% non-condensing |
| mounting | DIN rail,Panel/base mount,Busbar/cable-mounted |
| enclosure | Flame-retardant polycarbonate,ABS plastic |
| standards | IEC 61869-2,IEC 60044-1 |
| storageTemp | -25°C to +70°C |
| operatingTemp | -10°C to +55°C |
| accuracyClasses | [object Object] |
| insulationClass | E,F |
| secondaryOutput | 5 A,1 A |
| primaryCurrentRatings | 100 A to 6000 A |
Available Sizes
| dimensions | carton Quantity |
|---|---|
| 100/5 FP-24 | 100 |
| 150/5 FP-24 | 100 |
| 200/5 FP-24 | 100 |
| 300/5 FP-24 | 100 |
| 400/5 FP-24 | 100 |
| 200/5 DP-58 | 24 |
| 300/5 DP-58 | 24 |
| 400/5 DP-58 | 24 |
| 600/5 DP-58 | 24 |
| 800/5 DP-58 | 24 |
| 1000/5 DP-58 | 24 |
| 800/5 DP-88 | 20 |
| 1000/5 DP-88 | 20 |
| 1200/5 DP-88 | 20 |
| 1600/5 DP-88 | 20 |
| 2000/5 DP-88 | 20 |
| 1200/5 DP-812 | 18 |
| 1600/5 DP-812 | 18 |
| 2000/5 DP-812 | 18 |
| 2500/5 DP-812 | 18 |
| 3200/5 DP-812 | 18 |
| 4000/5 DP-812 | 18 |
| 4000/5 DP-614 | 18 |
| 4000/5 DP-816 | 10 |
| 5000/5 DP-816 | 10 |
| 6000/5 DP-816 | 10 |
